WARN XD-9000 Winch – Synthetic Rope Upgrade

Built on the legendary WARN XD-9000 platform, this winch delivers reliable 9,000 lb recovery performance with modern synthetic rope benefits – at a fraction of the price of factory synthetic models.

Product Overview

This XD-9000 comes upgraded from the original steel cable to a 30m × 10mm grey Sniper Core™ synthetic rope for lighter weight, safer handling, and easier use. It also includes a reversible billet aluminium fairlead, compatible with both inline and offset bullbar mounts.

Key Features

  • Genuine WARN XD-9000 9,000 lb rated line pull
  • 30m × 10mm grey Sniper Core™ synthetic rope
  • Reversible billet aluminium fairlead – inline & offset mounting
  • 12V high-speed series-wound motor (~4.6 hp)
  • 3-stage planetary geartrain, 156:1 ratio
  • Sliding ring gear freespool clutch
  • Automatic direct-drive cone brake
  • Handheld 12 ft (3.7 m) remote switch
  • Powder-coated finish for corrosion resistance

Performance Specifications (12V, first layer of drum)

Line Pull (lbs/kg) Line Speed (ft/min / m/min) Motor Current (amps)
0 lb / 0 kg 38 ft/min / 11.6 m/min 70 A
2,000 lb / 910 kg 14.4 ft/min / 4.4 m/min 180 A
4,000 lb / 1,810 kg 11 ft/min / 3.35 m/min 255 A
6,000 lb / 2,720 kg 8.67 ft/min / 2.64 m/min 330 A
8,000 lb / 3,630 kg 6.88 ft/min / 2.10 m/min 415 A
9,000 lb / 4,080 kg 6.38 ft/min / 1.94 m/min 460 A

Physical & Mounting Specs

  • Drum: 2.5" diameter × 9" length (6.4 cm × 23 cm)
  • Weight: ~35 kg (78 lbs) bare winch
  • Mounting bolt pattern: 10.0" × 4.5" (254 mm × 114.3 mm)
  • Recommended battery: Minimum 650 CCA

Why Choose This Winch?

  • Proven WARN XD-9000 durability and strength
  • Safer, lighter, and easier to handle synthetic rope
  • Flexible mounting with reversible billet fairlead
  • High performance at a fraction of factory synthetic price

(XD9000-SYN)

SKU XD9000-SYN
Model # 28500
Brand WARN
Shipping Weight 41.0000kg
Shipping Width 0.510m
Shipping Height 0.200m
Shipping Length 0.660m
Shipping Cubic 0.067320000m3
